Diving Deep: Unraveling Indirect, Nested, and Tree Recursion

#foundation #recursion #javascript #programming

8 min read, Wed, 30 Apr 2025

Banner Image

Recursion, the art of a function calling itself, is a powerful and elegant technique in computer science. While the concept of a function directly invoking itself is often the first encounter, the world of recursion extends beyond this direct approach. We discussed head and tail recursion in another article here. Today, we’ll delve into three intriguing variations: indirect recursion, nested recursion, and tree recursion, exploring their mechanics and applications.

Indirect Recursion

In direct recursion, a function calls itself within its own definition. Indirect recursion, however, introduces a chain of function calls. Imagine function A calling function B, which in turn calls function A (either directly or through another intermediary function). This creates a cyclical dependency where the recursion unfolds through multiple function invocations.

Consider this simple JavaScript example:

function isEven(n) {
    if (n === 0) {
        return true;
    } else {
        return isOdd(n - 1);
    }
}

function isOdd(n) {
    if (n === 0) {
        return false;
    } else {
        return isEven(n - 1);
    }
}

console.log(`Is 4 even? ${isEven(4)}`); // Output: Is 4 even? true
console.log(`Is 7 odd? ${isOdd(7)}`); // Output: Is 7 odd? true

Here, isEven calls isOdd, and isOdd calls isEven, demonstrating indirect recursion. The base cases (n === 0) in both functions are crucial to prevent infinite loops.

Time and Space Complexity of Indirect Recursion (isEven/isOdd Example):

In this specific example, the number of recursive calls is directly proportional to the input n. For each call, n is decremented by 1 until it reaches the base case (0). Therefore, the time complexity is O(n).

The space complexity is also O(n) due to the call stack. Each recursive call adds a new frame to the stack, and in the worst case, the depth of the recursion will be n.

Indirect recursion can be useful for structuring complex algorithms where different aspects of the problem are handled by separate, interacting functions. However, it can sometimes be harder to trace and debug compared to direct recursion due to the multiple function call layers involved.

To illustrate indirect recursion, consider the following sequence diagram:

sequenceDiagram
    participant A as isEven(n)
    participant B as isOdd(n)

    A->>B: isOdd(n - 1)
    B->>A: isEven(n - 1)
    A->>B: isOdd(n - 2)
    B->>A: isEven(n - 2)
    A-->>A: ... (base case reached)

When isEven(4) is initially called, the call stack might evolve as follows (simplified representation):

sequenceDiagram
    participant isEven_4 as isEven(4)
    participant isOdd_3 as isOdd(3)
    participant isEven_2 as isEven(2)
    participant isOdd_1 as isOdd(1)
    participant isEven_0 as isEven(0)

    isEven_4->>isOdd_3: calls
    isOdd_3->>isEven_2: calls
    isEven_2->>isOdd_1: calls
    isOdd_1->>isEven_0: calls
    isEven_0-->>isOdd_1: returns true
    isOdd_1-->>isEven_2: returns true
    isEven_2-->>isOdd_3: returns true
    isOdd_3-->>isEven_4: returns true

Nested Recursion

Nested recursion occurs when a recursive call has the recursive function’s call itself as one of its arguments. A classic example is the Ackermann function, a rapidly growing function defined recursively:

function ackermann(m, n) {
    if (m === 0) {
        return n + 1;
    } else if (n === 0) {
        return ackermann(m - 1, 1);
    } else {
        return ackermann(m - 1, ackermann(m, n - 1)); // Nested recursion here
    }
}

console.log(`Ackermann(2, 1) = ${ackermann(2, 1)}`); // Output: Ackermann(2, 1) = 5

Notice the line return ackermann(m - 1, ackermann(m, n - 1));. The second argument to the outer ackermann call is itself a call to ackermann. This nesting leads to a deeper level of recursion and can result in a significant number of function calls even for small input values.

Ackermann grows very rapidly and is often used to test the ability of compilers to optimize recursion. It is defined as follows for non-negative integers m and n:

A(m,n) = base case n+1      if m=0
A(m,n) = A(m-1,1)           if m>0 and n = 0
A(m,n) = A(m-1, A(m,n-1))   otherwise

Visualizing the call stack for nested recursion like the Ackermann function can become quite complex quickly due to its rapid growth. However, we can illustrate the nested nature with a simplified call structure for ackermann(2, 1):

sequenceDiagram
    participant A_2_1 as ackermann(2, 1)
    participant A_2_0 as ackermann(2, 0)
    participant A_1_1 as ackermann(1, 1)
    participant A_1_2 as ackermann(1, 2)
    participant A_1_3 as ackermann(1, 3)
    participant A_0_n as ackermann(0, n)

    A_2_1->>A_2_0: calls with nested ackermann
    A_2_0->>A_1_1: calls
    A_1_1->>A_0_2: calls
    A_0_2->>A_1_1: returns 3
    A_2_1->>A_1_3: calls with nested ackermann
    A_1_3->>A_0_4: calls
    A_0_4->>A_1_3: returns 5
    A_1_3-->>A_2_1: returns 5

Notice the nested calls within the arguments. The evaluation requires resolving the inner ackermann call before the outer one can proceed. This leads to a deep and branching call stack.

Time and Space Complexity of Nested Recursion (Ackermann Function):

The Ackermann function has a time complexity that is not easily expressed with simple big O notation. It grows extremely rapidly, much faster than exponential time. It’s related to the inverse of the Ackermann function, often denoted as α(n), which grows very slowly. The time complexity is roughly related to A(m,n), which is hyper-exponential.

The space complexity is proportional to the depth of the recursion stack. In the worst case, this can also grow very quickly, although somewhat slower than the time complexity.

Nested recursion can be powerful for defining functions with intricate growth patterns, but its complexity can make it challenging to analyze its time and space complexity. Understanding the order of evaluation is critical when dealing with nested recursive calls.

Tree Recursion

Tree recursion is characterized by a function making multiple recursive calls within its body. This branching pattern of calls resembles the structure of a tree. A common example is calculating Fibonacci numbers:

function fibonacci(n) {
    if (n <= 1) {
        return n;
    } else {
        return fibonacci(n - 1) + fibonacci(n - 2); // Two recursive calls
    }
}

console.log(`Fibonacci(5) = ${fibonacci(5)}`); // Output: Fibonacci(5) = 5

The call flow for fibonacci(4) proceeds as follows:

fibonacci(4) is called.
It calls fibonacci(3) and fibonacci(2).
fibonacci(3) calls fibonacci(2) and fibonacci(1).
fibonacci(2) (from step 2) calls fibonacci(1) and fibonacci(0).
fibonacci(2) (from step 3) calls fibonacci(1) and fibonacci(0).
fibonacci(1) returns 1 (base case).
fibonacci(0) returns 0 (base case).
The fibonacci(2) calls return 1 (1 + 0).
fibonacci(1) (from step 3) returns 1 (base case).
The fibonacci(3) call returns 2 (1 + 1).
fibonacci(1) (from step 4) returns 1 (base case).
fibonacci(0) (from step 4) returns 0 (base case).
The fibonacci(2) call (from step 2) returns 1 (1 + 0).
The initial fibonacci(4) call returns 3 (2 + 1). This demonstrates the branching nature of the calls, where fibonacci(2) and fibonacci(1) are calculated multiple times.

Time and Space Complexity of Tree Recursion (Fibonacci Example):

Without memoization, the fibonacci(n) function exhibits exponential time complexity, specifically O(2^n). This is because each call to fibonacci(n) makes two further recursive calls, leading to a binary tree of computations.

The space complexity is O(n), which is determined by the maximum depth of the recursion tree. In the worst case, the call stack will grow linearly with n.

Tree recursion is often used in algorithms that involve exploring multiple possibilities or dividing a problem into several independent subproblems, such as in tree traversals, searching algorithms (like depth-first search), and divide-and-conquer strategies. However, it’s crucial to be aware of potential inefficiencies due to repeated computations and consider optimization techniques like memoization.

Bonus Example: Tree Recursion in Tower of Hanoi

The Tower of Hanoi puzzle, which we discussed earlier, provides another excellent example of tree recursion. The recursive solution involves breaking the problem of moving n disks into two subproblems of moving n-1 disks, plus a single move of the largest disk.

Here’s the JavaScript code again:

function towerOfHanoi(n, source, target, auxiliary) {
    if (n === 1) {
        console.log(`Move disk 1 from ${source} to ${target}`);
        return;
    }
    towerOfHanoi(n - 1, source, auxiliary, target); // First recursive call
    console.log(`Move disk ${n} from ${source} to ${target}`);
    towerOfHanoi(n - 1, auxiliary, target, source); // Second recursive call
}

// Example usage:
towerOfHanoi(3, "A", "C", "B");

Recursive steps:

Move n-1 disks from source to auxiliary rod.
Move the largest disk (n) from source to target.
Move n-1 disks from auxiliary to target.

Call Tree Visualization (Simplified for 3 disks):

flowchart TD
    A["Move 3 disks from A to C (using B)"] --> B["Move 2 disks from A to B (using C)"]
    B --> C["Move disk 1 from A to C"]
    B --> D["Move disk 2 from A to B"]
    D --> E["Move disk 1 from C to B"]
    A --> F["Move disk 3 from A to C"]
    A --> G["Move 2 disks from B to C (using A)"]
    G --> H["Move disk 1 from B to A"]
    G --> I["Move disk 2 from B to C"]
    I --> J["Move disk 1 from A to C"]

Time and Space Complexity of Tree Recursion (Tower of Hanoi):

The Tower of Hanoi algorithm has a time complexity of O(2^n). This is because for each disk (except the smallest), the problem is essentially solved twice for a smaller number of disks.

The space complexity is O(n) due to the depth of the recursion stack. In the worst case, the stack will hold n function calls.

The Tower of Hanoi elegantly demonstrates tree recursion where the problem is broken down into two similar, smaller subproblems.

Conclusion

Indirect, nested, and tree recursion offer powerful ways to structure algorithms, allowing for elegant solutions to complex problems. While direct recursion forms the foundation, these variations expand the possibilities of recursive thinking. Understanding their nuances, potential complexities, and, importantly, their time and space complexities, is crucial for any programmer seeking to leverage the full power of recursion in their code. By recognizing these patterns and their performance implications, you can better design, analyze, and debug recursive algorithms in your full-stack development endeavors.
